If you've been following the series of posts I've written thus far, you will have already become familiar with the k-means clustering algorithm and how to determine the optimal number of clusters to produce using the algorithm. This clustering method, unfortunately, is only useful for numerical datasets. What happens if we want to cluster non-numerical data, such as names, locations, colors, and companies? The clustering algorithm I will cover is a variation of k-means that can be used on categorial data. This method is called K-Modes.

So, what is the K-Modes Algorithm?

The K-Modes clustering procedure is very similar to k-means, actually.

Lets say we have a small dataset of individual categorical data that we'd like to cluster into 3 groups:

	Education Level	Ethnicity	Occupation	Marital Status	State
P1	Associates	Hispanic	Analyst	Single	Florida
P2	Bachelors	Caucasian	Engineer	Divorced	California
P3	Masters	Native American	Engineer	Single	North Carolina
P4	Bachelors	Hispanic	Engineer	Divorced	California
P5	Associates	African American	Accountant	Married	Texas
P6	Associates	Caucasian	Engineer	Married	Texas
P7	Bachelors	Caucasian	Accountant	Widowed	Florida
P8	Associates	Asian	Teacher	Married	Texas
P9	Bachelors	African American	Accountant	Single	Florida
P10	Masters	Caucasian	Lawyer	Single	Texas

The process to cluster the dataset can be broken down to 4 steps.

Step 1: Select k data points at random to be initial center points

Just like with K-means, the method starts out with deciding the number of clusters desired and then choosing at random several points to be the initial center points for the algorithm.

From our little example dataset, we will choose P2, P6, and P9 as center points (centroids):

	Education Level	Ethnicity	Occupation	Marital Status	State
P2	Bachelors	Caucasian	Engineer	Divorced	California
P6	Associates	Caucasian	Engineer	Married	Texas
P9	Bachelors	African American	Accountant	Single	Florida

Step 2: Calculate dissimilarities between each datapoint and the center points

K-means used Euclidean distance to determine how similar (or dissimilar) a datapoint was to a centroid. K-modes uses a different method for determining similarity.

K-modes compares each datapoint to the centroids and count up the number of dissimilar attributes.

When we take P1 for example, and compare it to each centroid, here's what we get:

P1 => P2

	Education Level	Ethnicity	Occupation	Marital Status	State
P1	Associates	Hispanic	Analyst	Single	Florida
P2	Bachelors	Caucasian	Engineer	Divorced	California

Number of Dissimilarities: 5

P1 => P6

	Education Level	Ethnicity	Occupation	Marital Status	State
P1	Associates	Hispanic	Analyst	Single	Florida
P6	Associates	Caucasian	Engineer	Married	Texas

Number of Dissimilarities: 4

P1 => P9

	Education Level	Ethnicity	Occupation	Marital Status	State
P1	Associates	Hispanic	Analyst	Single	Florida
P9	Bachelors	African American	Accountant	Single	Florida

Number of Dissimilarities: 3

Step 3: Assign data points to a cluster

As with K-means, each datapoint is assigned to the centroid with the smallest dissimilarity score.

Below is a table containing the dissimilarities between each data point and the centroids and its assigned cluster.

	Cluster 1 (P2)	Cluster 2 (P6)	Cluster 3 (P9)	Assigned Cluster
P1	5	4	3	Cluster 3
P2	0	3	5	Cluster 1
P3	4	5	4	Cluster 1
P4	1	4	4	Cluster 1
P5	5	2	3	Cluster 2
P6	4	0	5	Cluster 2
P7	3	4	1	Cluster 3
P8	5	2	5	Cluster 2
P9	3	5	0	Cluster 3
P10	4	3	4	Cluster 2

Step 4: Calculate new cluster centroids

This step is where k-modes gets its name from. We compute the new centroids for each cluster by using the mode. If there are values that have the same number of occurrence, one of the values can be chosen at random.

The new centroids for each cluster are:

 Cluster 1

	Education Level	Ethnicity	Occupation	Marital Status	State
P2	Bachelors	Caucasian	Engineer	Divorced	California
P3	Masters	Native American	Engineer	Single	North Carolina
P4	Bachelors	Hispanic	Engineer	Divorced	California
New Centroid	Bachelors	Caucasian	Engineer	Divorced	California

Cluster 2

	Education Level	Ethnicity	Occupation	Marital Status	State
P5	Associates	African American	Accountant	Married	Texas
P6	Associates	Caucasian	Engineer	Married	Texas
P8	Associates	Asian	Teacher	Married	Texas
P10	Masters	Caucasian	Lawyer	Single	Texas
New Centroid	Associates	Caucasian	Accountant	Married	Texas

Cluster 3

	Education Level	Ethnicity	Occupation	Marital Status	State
P1	Associates	Hispanic	Analyst	Single	Florida
P7	Bachelors	Caucasian	Accountant	Widowed	Florida
P9	Bachelors	African American	Accountant	Single	Florida
New Centroid	Bachelors	Caucasian	Accountant	Single	Florida

Step 5: Repeat steps 2, 3 and 4

As with k-means, the algorithm  reassigns data points to clusters based on their similarity to the centroids. New centroids are then computed, and the process repeats until no changes in the cluster assignments are made.

Determining the optimal 'k'

Choosing the optimal number of clusters for k-modes can be done using a slightly modified version of the elbow method employed for k-means. Here's the steps to follow:

1. Perform K modes clustering for a range of values of k.
2. After each clustering, compute the  dissimilarity score between each datapoint and it's assigned cluster centroid, and add them up to get the total dissimilarity score.
3. Create a line plot of the total dissimilarity score for each value of k.
4. Finally look at the plot for the value of k where the dissimilarity score begins to decrease linearly. This value is your optimal number of clusters for the dataset.

Now that you know the k-modes clustering algorithm, what datasets do you plan of using it to cluster? Share your plans in the comments below.

Until next time! :)
